With MP3 player, support MP3 and WMA Tuner (AM&FM) function Chime and Siren function 3 AUX inputs, 2 MIC inputs, 1 AUX output MIC1 has priority (auto mute function) LED display for power, signal, clip Individual control for MIC and AUX input Master volume control Bass and treble control 70V, 100V and 8 ohms output Four zones output with separated volume control 4 loop play modes for MP3 player, 5 sound effects for user to choose Music name, played time, remain time display, EQ display. Remote control and stand by function
| جزییات | مشخصات |
|---|---|
| Model | PC-120 |
| Output | 120W |
| Output regulation | Less than 3dB, no load to full load |
| Speaker output | Balanced 8 Ohm |
| AUX output | 600 Ohm / 1V(0dBV) |
| Inputs | Mic 1,2,3/600 Ohm,2.0Mv (-54dBV),unbalanced |
| Inputs | AUX 1,2/10 K Ohm,250mV (-10dBV),unbalanced |
| Frequency response | 100Hz~16KHz |
| Distortion | Less than 0.1% at 1KHz,1/3 rated power |
| Signal to noise ratio | Microphone 1,2,3 : 66dB |
| Signal to noise ratio | AUX 1,2 : 70DB |
| Tone | Bass: +- 10dB at 100Hz |
| Tone | Treble: +- 10dB at 10KHz |
| Muting function | Mic 1 overrides other input signals with 0~30dB attenuation |
| Protection | AC fuse; DC voltage, overload and short Circuit |
| Power Requirements | AC 220~240V/50~60Hz |
| Power Consumption | 320W |
| Dimension (mm) | 482mm*380mm*110mm |
| Weight | 12.3Kg |
